Reflex Fillcontrol Plus User Manual

Installation
22
— English Fillcontrol Plus — 06.07.2016 - Rev. B
Terminal
number
Signal
Function
Wiring
1 PE
230 V power supply via mains cable and plug. Pre-wired 2 N
3 L
4 PE
Not used. 5 N
6 M1
10 Y1
Not used. 11 N
12 PE
13 COM
Group message (floating). User, optional 14 NC
15
NO
16 Not assigned
External makeup demand for level-dependent makeup.
• From a pressurisation station, for example.
(Set the controller to "Levelcontrol")
User, optional 17 Makeup (230 V)
18
Makeup (230 V)
19 PE shield
Not used.
20 - Level (signal)
21 + Level (+ 18 V)
22 PE (shield) Pressure analogue input.
• Display at the controller.
• Activation of the makeup.
– For the "Magcontrol" makeup variant
Pre-wired
23 - Pressure (signal)
24 + Pressure (+ 18 V)
25
0 – 10 V (correcting
variable)
Not used.
26 0 – 10 V (feedback)
27 GND
28 + 24 V (supply)
29 A
RS-485 interface. User, optional 30 B
31 GND
32 + 24 V (supply) Supply for E1 and E2. Pre-wired, bridged
33 E1
Contact water meter (in "Fillset Impuls", for example), see
chapter 4.6 "Optional equipment and accessories" on page 12 .
• Evaluation of the makeup.
• Contact 32/33 closed = meter pulse.
User, optional
34
E2
Not used.
Pre-wired, bridged
