13
Connecting straps are secured to the base frame upon delivery.
If a split setup is being installed, plastic connecting straps are provided (one per base) to
secure the bases together. Use both straps to secure the head and foot portions together.
Once the bases are in their desired position and turned
upright onto their legs, slightly loosen both legs to allow
the strap to fit on the leg bolt, between the leg washer and
frame.
Slide side (a) of the connecting strap onto leg bolt. Swing
the strap and connect side (b) to the leg bolt. Secure the
strap by shifting to the left.
Re-tighten legs. Do not over tighten. Use the remaining
strap on other end of the base.
OVERVIEW
STEP 2
STEP 1
connecting strap (optional)
a
b
STEP 3
