Reflexion Arc - Quick Reference Guide; System Wiring Diagram

5
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
If installing a split unit, see page 13-14.
Remote
Emergency Battery
Backup Strap
Underbed Lighting
Head Motor
Foot Motor
Foot
Massage
Motor
Head
Massage
Motor
Power
Cord
Power Supply
USB Ports
Input Cord
