Device Size and Distances
REFUsol 100K
982059/02
2020-11
3.4 Device Size and Distances
Fig. 6: Installation site: distances/free space
Fig. 7: Installation site: distances/free space
400 mm
(16 in)
200 mm
(8 in)
400 mm
(16 in)
200 mm
(8 in)
400 mm
(16 in)
200 mm
(8 in)
400 mm
(16 in)
200 mm
(8 in)
