REFU REFUsol 100K - 7.2 ConnectionBox Variants

Technical Data 43
ConnectionBox Variants
REFUsol 100K
982059/02
2020-11
EnglishDeutsch
7.2 ConnectionBox Variants
Tab. 13: Technical data ConnectionBox Variants
Decentral ConnectionBox Central ConnectionBox
Type
CBID 100K (1100V-PMH-DCS) CBIC 100K (1100V-R-DCS)
Art. No.
937P211.0001 936P001.0000
INPUT
Rated DC voltage
1 100 V
Max. current per input / total
25 A/250 A 250 A/250 A
DC connection
20 strings push-in clamp 6 … 16 mm
2
ring terminal block 50 … 240 mm
2
DC fuses (+ / - )
order separately (Art. No. 922028) order separately (Art. No. 922028)
DC circuit breaker
integrated integrated
DC overvoltage protection
order separately (Art. No. 922021/22 order separately (Art. No. 922021/22
OUTPUT
Rated AC voltage
180 to 480 V 180 to 480 V
AC overvoltage protection
order separately (Art. No.922023/24) –
Max. AC current
128 A 128 A
AC connection
L1–L3: M12, PEN: M10,
bolt terminals 50 … 240 mm
2
L1–L3: M10, PEN: M8 (min. 6 mm
2
),
bolt terminals 50 … 150 mm
2
Dimensions W × H × D
760 × 1007 × 166 mm 760 × 692 × 166 mm
Weight
40 kg 25 kg
