ST 1, STR 1 3
1.3 Data specified on electric actuator
Nameplate: Warning plate:
Nameplate contains the basic data concerning identification, performance and electricity: indication of producer,
type, serial number, max. load thrust and switching-off thrust, protection code, operating speed, supply voltage
and current.
Graphic symbols on electric actuator
The graphic symbols used on electric actuator substitute the text messages. Some of them are in accordance with
EN ISO 7010, ISO 7000 and IEC 60417 within valid edition.
Dangerous voltage (EN ISO 7010-W012)
Stroke of the electric linear actuator
Switching-off thrust
Manual control (0096 ISO 7000)
Protection terminal (5019 IEC 60417)
1.4 Warranty conditions
The supplier is responsible for completeness of the delivery and guarantees proprieties of the product,
stated by technical conditions (TC), or proprieties agreed upon on purchase contract.
The supplier is not responsible for product deteriorated properties caused by the customer during storing,
non professional assembly, or non professional operation.
1.5 Under-guarantee and after-guarantee service
Our customers are provided with professional service of our firm in installation, operation, service, maintenance,
revision and help in troubleshooting for all our products.
Trained professionals wait for you also in our contracted service centres.
Under-guarantee service is performed by the service department of the production plant, or by a
contracted service centre according to a written claim.
In case of occurring of any fault please let us know it and state:
• type code
• serial number
• ambient parameters (temperature, humidity...)
• duty cycle including frequency of switching
• type of switching-off (position or thrust)
• set switching-off thrust
• type of fault - description of claimed fault
• it is recommended to place also Installation certificate.
It is recommended to have after-guarantee service performed by the service department of the
production plant, or by a contracted service centre.
