use of a ball and saddle joint. Slide the ball through the
saddle until it stops, then secure the joint from behind by
sliding the tethered pin through the saddle.
From the storage position, un-clip and fully unroll the
sunshade. Extend the sunshade over the sport tower top
and attach the sunshade to the sport tower by use of the
eyelet snaps.
Finally, apply tension to the front end of the sunshade to
secure it in place while in motion. Attach the straps on
the forward side of the sunshade to the camel back eye
straps located on the sport tower’s frame. After connecting
the carabiner clips on the port and starboard side, your
sunshade is ready for recreation.
For trailering and storage purposes, the sport tower can be left on the
boat, but the sunshade must be rolled up and stored in the boot. The
sunshade assembly must be collapsed back against the sport tower
and clipped around the sport tower with the quick release clips. This
is also how the sunshade should be stored with speeds exceeding 35
miles per hour. Be aware of potential carbon monoxide buildup while
the sunshade is in use.
!
WARNING
AVOID PROPERTY DAMAGE AND PHYSICAL INJURY. DO NOT
USE THE SUNSHADE ABOVE A SPEED OF 35 MILES PER HOUR.
Sunshade Warning
6-13
Equipment Operations
2)
3)
