Regal 2100 - Page 293

2100 RX TOWER SPEAKER WIRING 1 0F 2
2300 JETPORT DRIVE
ORLANDO, FLORIDA 32809
TEL (407) 851-4360
ALL RIGHTS RESERVED
REGAL MARINE INDUSTRIES
RX TOWER SPEAKERS WIRING
DR. BY:
WI-887
PAGE NO.:
APP. BY: DWG. NO.:
REVISION DESCRIPTION
M.GARCIA
1 OF 2
DR. BY:
REV. DATE:
5/16/08
CHECK BY:
DRAWING TITLE:
APP. BY:
DATE:
M.GARCIA
2
SPEAKERS WILL BE ADJUSTED FOR PROPER SPACING.
PIGTAILS WILL BE TUCKED BACK INTO THE TOWER PIPE. THE
OUTER MOST SPEAKERS WILL BE CONNECTED. THE OTHER UNUSED
CONFIGURATION, WHEN ONLY TWO SPEAKERS ARE USED, ONLY THE
* TOWER SPEAKERS ARE WIRED IN PARALELL IN QUAD
SEE DETAIL "A'
134
