CHAPTER 6
6-40
Operation
Power On. When the helm is powered up by the key switch 12 volt
DC energy is available at the depth gauge along with the remainder
of the instrument cluster. You do
not need to press the “ON/OFF
MODE” keypad.
The LCD will illuminate showing the depth and the type of units
selected; feet (FT), meters (M), or fathoms (F). To deactivate the
depth sounder, hold the “ON/OFF MODE” keypad for 4 seconds.
If you press the “ON/OFF MODE keypad again the unit will be
reactivated.
Depth Alarm. Shallow mode: If you press the “ON/OFF” MODE”
keypad again the “SH” shallow depth alarm setting is displayed. This
is the shallowest water that will energize the alarm. Press and hold
the up or down arrow keypads to adjust the reading to the desired
depth.
Depth Alarm. Deep Mode: By pressing the “ON/OFF MODE” key-
pad displays again the “DP” deep depth alarm setting. This is the
deepest water that will energize the alarm.
Press and hold the “UP” or “DOWN” keypads to adjust the reading
to the desired depth. When the shallow depth setting is read by the
depth finder, the “SH” will flash on the LCD and the audible alarm
will sound in a rapid sequence. When the deep depth setting is read
by the depth finder the “DP” will flash on the LCD and the audible
alarm will sound at 2 beeps per second.
Note: To fully deactivate the alarm, reset it to zero. Pressing the
“ON/OFF MODE” keypad temporarily deactivates the alarm. To
reactivate the alarm press the “ON/OFF MODE” keypad until the
depth reading appears.
CHAPTER 6
6-40
Operation
Power On. When the helm is powered up by the key switch 12 volt
DC energy is available at the depth gauge along with the remainder
of the instrument cluster. You do
not need to press the “ON/OFF
MODE” keypad.
The LCD will illuminate showing the depth and the type of units
selected; feet (FT), meters (M), or fathoms (F). To deactivate the
depth sounder, hold the “ON/OFF MODE” keypad for 4 seconds.
If you press the “ON/OFF MODE keypad again the unit will be
reactivated.
Depth Alarm. Shallow mode: If you press the “ON/OFF” MODE”
keypad again the “SH” shallow depth alarm setting is displayed. This
is the shallowest water that will energize the alarm. Press and hold
the up or down arrow keypads to adjust the reading to the desired
depth.
Depth Alarm. Deep Mode: By pressing the “ON/OFF MODE” key-
pad displays again the “DP” deep depth alarm setting. This is the
deepest water that will energize the alarm.
Press and hold the “UP” or “DOWN” keypads to adjust the reading
to the desired depth. When the shallow depth setting is read by the
depth finder, the “SH” will flash on the LCD and the audible alarm
will sound in a rapid sequence. When the deep depth setting is read
by the depth finder the “DP” will flash on the LCD and the audible
alarm will sound at 2 beeps per second.
Note: To fully deactivate the alarm, reset it to zero. Pressing the
“ON/OFF MODE” keypad temporarily deactivates the alarm. To
reactivate the alarm press the “ON/OFF MODE” keypad until the
depth reading appears.
