Regal 2200 - Bilge Pump

CHAPTER 7
7-18
Bilge Pump
The bilge pump is usually installed in the engine compartment just
below the engine front. Check for foreign materials stuck in the
strainer area or discharge hose.
Check all clamps and electrical connections for tightness. A quick check
of the bilge pump automatic float switch is afforded by lifting up on
the float and listening for the pump operating. Look around the float
area for foreign debris and remove as necessary.
Fuel Tank & Fittings
Periodically (at least once a year) inspect the fuel tank components for
loose clamps at the vent, fill and feed locations. Examine each hose
for signs of deterioration and leakage. Check the fuel sender for loose
bolts, nuts, and leaks at all areas of contact. Also, inspect the fuel tank
for signs of leakage or abrasion. Tighten all components as needed.
HOSE CLAMPS
FUEL FEED
FUEL SENDER
ANTI-SIPHON VALVE
TYPICAL FUEL TANK
FUEL VENT
FUEL FILL
