CHAPTER 6
6-32
As an option Regal
Vue is installed as
shown. Each unit
is outfi tted with a
memory card with
predetermined
geographical re-
gions. Should the
operator want a
different memory
card access to the
Regal Vue panel is
outlined below.
1. The battery switch should be turned to the
“off ” position before starting to work behind
the dash. At the rear of the Regal Vue display
(behind the dash) you will see a small com-
partment with 2 allen head type fasteners.
Remove both fasteners with the panel cover
to access the memory card compartment.
2. Insert a fi ngernail or small slotted screw-
driver into the memory card end tab. Push up
to disengauge the card. Next, pull down on
the card to remove it from the card slot.
INSTALLING/REMOVING MEMORY CARD
FASTENERS
