Equipment Operation
6-59
Transom Trim Switch
A stern drive trim switch is
located on the transom. It per-
mits tilting the stern drive in the
“up” or “down” positions from
the stern of the boat. Note that
this switch travels a complete
up and down cycle from the
lowest down trim position to
an up trailering positon. Always
remove the keys from the igni-
tion switch when engine is not running. Make sure nobody is near the
stern drive when using the tilt switch. Make sure the stern drive unit is
in a complete down position before starting the engine. Failure to do
so may result in stern drive component damage.
Underwater Lighting
As an option light bars w/ LED
bulbs make up the underwater
lighting system. The lights are
located on the transom on both
port and starboard sides of the
stern drive. There is a dash switch
for energizing the lights. The un-
derwater lights circuit protection fuse is found in the under dash fuse
block and is rated at 10 amp.
