Systems
4-3
WIRE COLOR CODES (CON’T.)
Color Gauge Function
Blue 10 Cabin Light Main Feed
Blue/White 16 Transom Courtesy Lights
Gray 16 Bow, Navigation Lights
Gray/White 16 Mast Light (Fwd. Running)
Gray/Black 16 Mast Light (Anchor Light)
Red/Black 16 Windlass Up
Red/White 16 Windlass Down
Red 16 Gas Vapor Detector, Stereo
Remote, Breaker To Dash
Feed Leads
Red 2/0 Main DC Panel Feed
Red 2 Positive Feed, Starter, Battery
Red 4 Positive Feed
Red 6 Positive Feed, Alt. Charge
Red 8 Positive Feed, Alt. Charge
Red 14 Positive Feed, Electronics
Yellow/Black 16 Tank Monitor
Purple 16 Hour Meter
Green 8 Bonding
Green 16 Tank Level Monitor
Pink 16 Fuel Tank Sender Feed
