16
Chapter 7
SEAT-HELM
The helm seat features an electric hydraulic mechanism
which moves the captiain’s seat fore-aft and up-down to
accommodate different body types and cruising options.
The helm seat features a leaning post to gain extra height
or additional standing room at the helm when maneuver-
ing in close quarters.
There is a dual set of toggle style switches to the starboard
side of the helm. The arrows on the switches depict the
function. See the illustration on the right.
To add seat height using the leaning bolster lift the front
of the helm seat upward. This permits the leaning bolster
to rotate upward until fully extended. See the illustration
below.
Flip Up Legs And
Pull Latch For
Increased Stand-
Up Height
Helm Seat
Switches
CAPTAIN’S SEAT SWITCHES
SEAT-HELM-USING TEAK PLATFORM
Flip Front Cushion
Up For Increased
Standing Room
Latch
