Technical Information
12-27
42 SC PLUMBING DRAIN RUNS
BILL OF MATERIALS
01
ITEM
WLFHL20B
DESCRIPTION
PART #
1 Water Tank Floor
QTY.
PROPRIETARY AND CONFIDENTIAL
DR. BY
DATE:
MLF23C - 5
DWG. NO.:
DRAWING TITLE:
Matt.B
DRAWN BY:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION
IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF
REGAL MARINE INDUSTRIES IS PROHIBITED
SHEET:
REVISION DESCRIPTION
APP. BY
FILE NAME
APPROVED BY:
REGAL MARINE INDUSTRIES
ALL RIGHTS RESERVED
SCALE:
REV. DATE
4060 LF Drain Runs
1
04.05.10
2300 JETPORT DRIVE
ORLANDO, FLORIDA 32809
TEL (407) 851-4360
Sink Runs Overboard ( 1" Wast Hose )
Sink Runs Overboard ( 1" Wast Hose )
Shower Box
FWD Toilet ( 1 1/2" Wast Hose )
Shower Box
Shower Drain ( 1 1/2" XHD )
FWD Sink ( 1" XHD )
Head Drain ( 1 1/2" XHD )
FWD Head Sink ( 1" Wast Hose )
AFT Toilet ( 1 1/2" Wast Hose
To AFT Shower Box ( 5/8" XHD )
Pump Out ( 1 1/2" Waste Hose )
AFT A/C Drain
( 1/2" XHD )
FWD Shower Box
( 5/8" XHD )
AFT BilgeFWD Bilge
Note: Double Fittings Putout
Shower Box Drain ( 1 1/2" XHD )
Manifold
Shower Box Drain / Through Fire Wall
AFT Shower
FWD Shower Box
AFT A/C Drain
Drain
Drain
WAIST TANKWATER TANK
FWD Bilge
Drain
A/C
AFT Bilge
42 SC Drain Runs
Note: FWD Head Drain & FWD Shower
connected togeather with a T
Vent ( 1" Wast Hose )
A/C
To Next Page
