23
Systems
TYPICAL ENGINE IGNITION SWITCH
On select yachts dual ignition switches are used to crank
over and start the diesel engines. The left ignition switch
controls the port engine and the right ignition switch con-
trols the starboard engine.
Other yachts use the newer Volvo “E” key system.
Each ignition switch features 3 positions.
STOP- SPRING LOADED TO THE LEFT.
ON- SUPPLIES IGNITION POWER TO ENGINE.
START- SPRING LOADED TO THE RIGHT.
Each ignition switch features 3 positions.
Refer to the engine chapter for further information.
Other yachts use the E-key system for starting engines.
Note: See the engine operatior’s manual for additional de-
tailed information.
AVOID POSSIBLE BODILY INJURY OR DEATH!
REMOVE KEYS FROM THE IGNITION
SWITCHES WHEN THE ENGINES
ARE NOT RUNNING.
