25
Systems
TYPICAL BATTERY MANAGEMENT SYSTEM-COMPONENT BREAKER DESCRIPTION
DASH MAIN- protects dash operation switch functions,
hardtop control panel, and engine hatch panel. In addi-
tion, it controls components located on the helm breaker
sub-panel located in the main stateroom electronics lock-
er. See the illustration for more information.Volvo engine
functions are not controlled by the dash main breaker.
CABIN MAIN- protects the cabin main DC panel
which controls direct current switch functions through-
out the vessel.
ELECTRONICS- protects all electronic dash equip-
ment components along with the stereo components. In
addition, this breaker controls all breakers from the elec-
tronics through the sirius weather on the helm breaker
panel located at the starboard helm seat locker.
WINDLASS- protects the deck mounted anchor wind-
lass circuitry.
CHARGER- This breaker protects the port battery
charger circuitry.
CHARGER- This breaker protects the “house” battery
charger circuitry.
CHARGER- This breaker protects the starboard battery
charger circuitry.
ACC (ACCESSORY)- protects any add-on equipment
components. If adding components ensure that the am-
perage does not exceed the safe limits of the breaker.
HYD. LIFT- protects the middle bilge pump circuitry.
CABLE REEL- protects the optional shore power hose
reel.
HOSE REEL- Protects the optional hose reel wash-
down system.
OIL CHANGER- protects the engine and generator oil
changer pump circuitry located in the bilge.
HATCH LIFT- protects the aft engine hatch circuitry.
FWD. BILGE PUMP- protects the forward most bilge
pump.
AFT BILGE PUMP- protects the aft bilge pump lo-
cated in the engine room under the center diamond plate
fl oor section between the engines.
HIGH WATER ALARM- protects the bilge high wa-
ter alarm. This audible alarm sounds at the dash should
bilge water reaches a predetermined level. Normally this
would indicate large volumes of water are entering the
bilge since normal amounts would be drawn overboard
via the bilge pump system.
STEREO MEMORY- protects the stereo system mem-
ory circuit and the stereo unit itself.
SHOWER PUMP- protects the aft/forward shower
sump pump circuitry.
POWER SEAT- protects the helm seat up/down along
with the forward/aft circuitry.
HOSE REEL- Protects the optional hose reel wash-
down system.
