LRI4E / HRI4E Direct Vent Gas Insert | 27
|
27
installation
6. Position Log 5 by seating into the indent located at the front of the
burner towards the right as shown below.
7. Log 6 is positioned in the indent on the far right of the burner in the
orientation shown below.
8. Line up the pin locator in Log 7 with the pin in Log 1.
9. When Log 7 is seated, manoeuvre it is contacting Log 2.
Placement of Log 4
Location for Log 5
Final Install
Log 7 and Log 2 should make contact
Log 7 pin locator line up with Log 1 pin
Location for Log 6
4
1
7
2
7
3
5
6
1
1
2
3
4
6
7
5
5. Seat Log 4 into front, right depression on burner as shown below.
