Regency LRI4E - Optional Mantel Deflector Installation

LRI4E / HRI4E Direct Vent Gas Insert | 37
|
37
installation
OPTIONAL MANTEL DEFLECTOR INSTALLATION
09.22.14
919-421
1
MANTEL DEFLECTOR INSTALLATION
Note: A mantel deector may be installed to reduce the minimum mantel
height. Refer to minimum clearances in the installation manual.
1. Line up the mantel deector (tabs to the back) with the Faceplate Back-
ing Plate.
TOLERANCES UNLESS 3RD ANGLE
Installed mantel deector
Mantel Deector
Vignette Faceplate
Note:
A mantel deector may be installed to reduce the minimum mantel height.
Refer to minimum clearances in the installation manual.
1
. Line up the mantel deector (tabs to the back) with the Outer Faceplate.
Secure in place with three screws prior to installing outer faceplate.
Note: Faceplate may be installed after the unit is in its nal position.
Low Prole Faceplate LRI4E/HRI4E Only
2. Bend all 3 tabs 90º to secure the deector to the top of the backing plate.
The tabs should be ush with the underside of the top lip of the back plate.
Top of backing
plate
