Doc ID: 191-7913A
2. Install the new Rekluse center hub into the clutch
basket. Make sure the thrush washer is still in place.
3. Reinstall the new Rekluse tab washer and center clutch
nut.
4. Using the 27 mm socket and
torque wrench, torque the center
clutch nut to 50 ft-lb (68 N-m).
5. Using the channel-lock pliers,
bend up both tabs of the tab
washer around the nut.
6. Seat the 6 OE drive pins into
the Rekluse inner hub.
To Next Page
