Doc ID: 191-7913A
Step 1: Find the starting point
a) With the bike standing up, locate the adjuster screw in
the center of the adjustable slave cylinder.
b) With the O-ring showing, use a 4 mm hex key to turn
the adjuster screw clockwise until it stops under light
pressure. This is your “starting point.”
NOTE: The resistance you feel is where the throw-out
begins to lift the pressure plate. Finding the right starting
point may take a few tries, but you will feel a noticeable
change in turning effort once you reach that point. Stop
when you feel the pressure increase. The “starting point” will
change as the clutch pack wears over time.
c) Once you have found the starting point, note the
position of the hex key using the tick marks on the slave
cylinder housing and the small etch mark located on the
screw. You will begin here to adjust the installed gap.
