Doc ID: 191-7913A
Configuration chart
Changing the springs
1. Using a flat-blade screwdriver, push the ¼ turn pin in far
enough to clear the opposite side of the EXP to unlock
the pin.
2. With the pin still pushed past the base, turn 90° to
remove the pin and spring.
ENGAGEMENT SETTING
250 350
Low
6 Silver 3 Silver & 3 Steel
Medium
3 Silver & 3 Red 6 Silver
Medium High
NA 3 Red & 3 Silver
High
6 Red 6 Red
