Rekluse RadiusCX - Step 4: Adjust the installed gap and Recheck Free Play Gain

Doc ID: 191-7913A
Doc Rev: 082018
Pg. 37
7. Place the bike in NEUTRAL and
recheck Free Play Gain.
8. Continue to step 4 to adjust the
installed gap until the Free Play
Gain of the clutch lever is 1/8”-1/4”
(3 mm-6 mm).
NOTE: Your clutch pack will expand
with heat, so final adjustment to Free
Play Gain should be made when the
bike is warm. Remember not to ride
without sufficient Free Play Gain.
Recheck Free Play
Gain and adjust the
installed gap
Do not perform 3
rd
gear starts with this product.
Starting in 3
rd
gear will burn up the clutch and decrease
the performance of this product in a short amount of
time.
Step 4: Adjust the installed gap and
Recheck Free Play Gain
Once you have learned how to check Free Play Gain, you
need to finish adjusting the installed gap, then recheck the
Free Play Gain until the clutch lever moves only 1/8” (3 mm).
The gap is adjusted by turning the slave cylinder screw.
a) With the bike running and in NEUTRAL, locate the
adjuster screw in the center of the adjustable slave
cylinder.
