PHYSICAL LAYOUT
FIGURE 2: MACH-PRO(WEB)COM PHYSICAL LAYOUT
TEK Mounting Screws (4) #8 x 1.5”
High
Impact
ABS Plastic
Power
EIA-232
PC/Modem
SMART-Net
EIA-485
MS/TP-Net
EIA-485
AUX-Net
10/100 Base T
Ethernet
