NOTE 3: The amber turn signals are not used, instead, the brake lights become the turn signals
and brake lights for towing only.
NOTE 4: Refer to electrical schematic, page 10, for steps listed below.
Step 1. Start at the driver side taillight assembly. Access the wires for the taillight assembly.
Step 2. Turn ON the taillights.
Step 3. Ground the continuity tester to a suitable ground.
Step 4. Probe each wire to locate a “HOT” wire. Turn OFF and ON the taillight switch to
verify the correct wire. Label the wire “LEFT TAILLIGHT”. Follow the same
procedure for the passenger side taillight assembly, but label the wire “RIGHT
TAILLIGHT”. Turn OFF the taillights.
Step 5. Have an assistant depress the brake pedal. Start at the driver side taillight assembly.
Probe each wire for a “HOT” wire. Have the assistant depress the brake pedal ON
and OFF to verify the correct wire. Label the wire “LEFT TURN/BRAKE”. For
the passenger side taillight assembly, follow the same procedure, but label the wire
“RIGHT TURN/BRAKE”.
Step 6. Refer to electrical schematic, page 10, return to the driver’s side taillight assembly.
Turn ON the taillights; locate the wire labeled “LEFT TAILLIGHT”. Cut the wire.
Confirm that the taillight goes OUT. Turn OFF taillights. Strip each wire ¼” crimp
a ¼” red female terminal onto each wire. Connect the wire that goes to the taillight
bulb to the “OUTterminal of the diverter. Connect the remaining wire to either
“IN” terminal of the diverter. For the passenger side taillight assembly, locate the
wire labeled “RIGHT TAILLIGHT” and follow the same procedure as above.
Step 7. Return to the driver side taillight assembly. Have the assistant depress the brake
pedal. Locate the wire labeled “LEFT TURN/BRAKE”. Cut the wire. Confirm that
the brake light goes OUT. Strip each wire ¼”. Crimp a ¼” red female terminal onto
each wire. Connect the wire that goes to the brake light bulb to the OUT” terminal
of the diverter. Connect the remaining wire to either “IN” terminal of the diverter.
For the passenger side taillight assembly, locate the wire labeled “RIGHT
TURN/BRAKE” and follow the same procedure as above.
