INSTALLATION OF CONDUCTOR CABLE
NOTE 1: Refer to electrical schematic, page 10 for the following steps.
NOTE 2: For driver and passenger side conductor cable installation, two separate wires will
be routed between the driver side and passenger side taillight assembly, either inside
the trunk area or underneath the vehicle.
Step 1. Route the conductor cable from the socket underneath the vehicle along the
passenger side to the passenger side taillight assembly.
NOTE 3: At the taillights, eight feet of two conductor will be needed to run from driver side
to passenger side (not supplied).
Step 2. Separate the conductor cable wires sufficiently to attach the diverters. Strip each
wire ¼”. Crimp a ¼” blue female terminal onto the green conductor wire. Connect
the green conductor wire to the remaining “IN” terminal of the “RIGHT
TURN/BRAKE” diverter.
Step 3. Using a single, 10ga, ¼” yellow female terminal, crimp together the red wire from
the two conductor and the brown wire from the three conductor. Connect it to the
remaining “IN” terminal of the “RIGHT TAILLIGHT” diverter.
Step 4. Using a butt connector, crimp one side to the black wire of the two conductor and
the other side to the yellow wire of the three conductor. Extend the two conductor
to the driver side taillight assembly. Locate the left taillight diverter and connect the
red wire to it. Locate the “LEFT TURN/BRAKE” diverter and connect the black
wire to it.
Step 5. Test the lube pump, diverter, and conductor cable installation before the installation
of wiring harness on the motor home.
For Installation Testing (pg 19), Towing Checklist (pg 20),
and Troubleshooting (pg 21) see the back section of the this Manual.
