19
TESTING THE INSTALLATION
Step 1. To test the wiring just completed, first turn ON the ignition switch in the motor
home. If the monitor switch is in the OFF position, the monitor will remain mute.
Turn the monitor switch ON and an alarm tone will sound and the red light will
illuminate. When driving the motor home by itself (not towing), the monitor should
be in the OFF position.
Step 2. Test the wiring completed in the towed vehicle to the rear socket of the motor home
using the coiled cable provided. If the plug feels loose in the socket, the pins in the
socket can be spread with a slotted screwdriver so contact is tight.
Step 3. Turn ON the ignition switch in the motor home. If the monitor switch is in the OFF
position, the alarm tone and the red light will come on and remain on until the
monitor switch is turned on. Turn the monitor switch ON. The alarm tone and red
light should go OFF in 10-30 seconds as soon as the pump builds up pressure in the
transmission of the towed vehicle. At this point when the alarm tone and red light
go OFF, the green light should illuminate if the system is functioning correctly. If
the alarm tone and red light remain ON after 30 seconds, this indicates the pump is
not running or there is a wiring error. Recheck the circuitry to make certain all wires
are connected properly.
Step 4. Turn ON the taillights and left and right turn signals to confirm that each respective
light glows on the towed vehicle.
Step 5. This completes the installation and testing of the Motor Coach Side of Lube Pump
System.
NOTE: WHEN INSTALLATION HAS BEEN COMPLETED, THE INSTALLER
NEEDS TO RETURN THE INSTALLATION INSTRUCTION BOOKLET
TO THE END CUSTOMER. ALSO, THE WARRANTY CARD INCLUDED
IN THE BOOKLET NEEDS TO BE COMPLETED AND RETURNED TO
REMCO INDUSTRIES.
