Carte : généralités (HJB - Renault)
CARD: general information (3/3)
Insert the strap into the 8 component
and pass the end of the strap through
the buckle.
Position the strap at the 6 opening and
close the cartridge.
Note: check that the diameter of the 7
strap cord fits the 6 opening.
Fitting a strap 7
Slide the rear casing 5 downwards
while pressing on zone A.
A
5
7
6
8
