Aérateurs (sorties air) (HJB - Renault)
Air Vents
AIR VENTS, air outlets (1/2)
6
2 1
1
5
1 Side air vents
2 Demister outlets for side windows
3 Windscreen demisting vents
4 Centre air vents
5 Footwell heater outlets for front
passengers
6 Control panel
7 Footwell heater outlets for rear
passengers (depending on the
vehicle)
8 Rear console air vents
5
4
3
2
7
8
3
3
