Aérateurs (sorties air) (HJB - Renault)
Central 4, side 1 and rear air
vents 8
Air flow
To close: move the cursor 9 towards the
outside of the vehicle beyond the resist-
ance point.
To open: move the cursor 9 towards the
inside of the vehicle.
Direction
Move the cursor 9 to the desired posi-
tion.
AIR VENTS, air outlets (2/2)
1
9
Do not add anything to the
vehicle’s ventilation circuit
(for example, to remove
bad odours).
There is a risk of damage or of
fire.
4
7
Rear seats
(depending on vehicle)
Passenger footwell heater outlets 8.
Do not attach any objects to the air
vents (e.g. telephone mounting).
Risk of damage.
9
8
9
