Air conditionné manuel (HJB - Renault)
MANUAL AIR CONDITIONING, HEATING SYSTEM (6/6)
1
2
3
5
4
Rear screen de-icing/
demisting
With the engine running, press
button 2. The operating tell-tale comes
on.
This function permits rapid demisting/
de-icing of the rear screen and de-icing
of the door mirrors (on equipped vehi-
cles).
To exit this function, press button 2
again. Warning light goes out.
Demisting automatically stops.
Rapid demisting
Turn controls 1, 3 and 5 to:
– demisting
W;
– the fan speed in position 3 or 4;
– maximum temperature.
Press the 4 button to deactivate the air
recirculation (warning light off).
