armrest
front ......................................................
(current page)
file ..............................................................
(current page)
adjusting your driving position ...................
(up to the end of the DU)
front seat adjustment
electric controls ....................................
(current page)
front seat adjustment .................................
(up to the end of the DU)
seats
front seat with electric controls ............
(current page)
front seats
adjustment ...........................................
(up to the end of the DU)
1.21
ENG_UD73754_2
Sièges avant (HJB - Renault)
Adjusting the seatback
To tilt the seatback
Activate the 2 switch forwards or back-
wards, or depending on the vehicle, lift
the 5 handle and tilt the seatback to the
desired position. Release the handle at
the desired position and make sure that
it is locked.
Adjusting the seat position
To move the seat forwards or back
Move the 1 switch forwards or back-
wards or, depending on the vehicle,
lift and hold the 3 handle to unlock the
seat. Release the handle once the seat
is in the correct position and ensure
that the seat is locked.
To raise or lower the seat base
Move the 1 switch up or down or, de-
pending on the vehicle, move the 4
lever as many times as necessary up-
wards or downwards to the desired po-
sition.
FRONT SEATS (1/2)
4
3
For safety reasons, carry
out any adjustments
when the vehicle is not
being driven.
We would advise you not to recline
the seatbacks too far to ensure that
the effectiveness of the seat belts is
not reduced.
Nothing should be placed on the
floor (area in front of driver) as such
objects may slide under the pedal
during braking manoeuvres, thus
obstructing its use.
5
1
2
After making adjustments,
make sure that the seat-
backs are correctly locked
in place.
