TOP AND FRONT OF ENGINE
Timing belt
11
Align tensioner marks (6) and (7) using a 6 mm
hexagonal wrench at (B).
15256R
Pretighten the tensioner nut to a torque of 0.7
daN.m.
Tighten the accessories crankshaft pulley bolt to a
torque of 2 daN.m (Top Dead Centre pin still in
place in the crankshaft).
NOTE: do not turn the tensioner anti-clockwise.
11-29
