Renault KlGER - Page 159

1.3
ENG_UD71311_2
Fusibles GPL X52 (XBC - Renault)
Number Allocation
A Defogger
B Anti-pinch
C Child safety
D
Power window - Front and
Rear
E Ignition primary supply
F Power window - Front
G
Air conditioning - Manual/
Automatic
H
Backup light - Continuous
variable transmission
/ Automated manual
transmission
I Accessory socket
Number Allocation
1 Not used
2
Day light running light /
Ambient lighting
3
Continuous variable
transmission
4 Not used
5 Child safety
6 Rear power window
7
BCM/Multimedia/
Accessory socket/
Accessory relay coil
8 Hands free mode
9 Hands free mode
10 Not used
11
Starter - Non Handsfree
mode variant
12
Roof lamp - Front/Rear
/ Anti-pinch relay coil /
Power window relay coil /
Automatic Air conditioning
unit
FUSES (3/4)
Number Allocation
13 Cluster
14 Combination switch
15
Radio/Ultra low cost
navigation/BIA/Diagnostic
socket
16 Combination switch
17 BCM
18 Horn
19 Door latch / Tail gate latch
20 BCM
21 to 23 Not used
24
BIA / Outer rear view
mirror
25
Defogger relay coil /
multifunction switch
(defogger)
26
Backup light/Rear wiper
washer/neutral sensor
27 Front wiper
