Renault KlGER - Page 160

1.4
ENG_UD71311_2
Fusibles GPL X52 (XBC - Renault)
Number Allocation
28
Fuel pump relay coil/BCM/
ECU/Powertrain control
unit/Gear shift lever/
Cluster
29 Electronic power steering
30 Airbag
31 Stop lamp
32
Transponder/Clutch travel
end switch/stop lamp/ABS
33
Second row accessory
socket
34 to 36 Not used
37
Air conditioning - Manual /
Automatic
38 to 41 Not used
42 Anti pinch
43
Front anti-pinch power
window
Number Allocation
44 First row accessory socket
45 Position lamp
46
Right hand side low beam
headlamp
47
Left hand side low beam
headlamp
48
Right hand side high beam
headlamp
49
Left hand side high beam
headlamp
FUSES (4/4)
