3.26
Ashtray 4, 7
(depending on the vehicle)
You can use the ashtray by pushing
cover 1 in the direction shown by the
arrow or by pulling cover 7. To empty it,
pull side 3 or press tab 6.
To close cover 1, push it again in the di-
rection shown by the arrow.
CIGAR LIGHTER, ACCESSORIES SOCKET, ASHTRAY
1
2
Accessories socket 5
(depending on the vehicle)
The accessories socket is designed for
connecting accessories with a maxi-
mum power rating of 120 Watts (volt-
age: 12V, 10A).
4
5
3
7
6
Cigar lighter 2
Open cover 1 by pushing it in the direc-
tion shown by the arrow.
With the ignition on, push in cigar
lighter 2
It will spring back with a click when it is
ready. Pull it out to use. After use, re-
place it without pushing it all the way in.
Removing cigar lighter 2 provides
access to an accessories socket.
Connect accessories
with a maximum power of
120 Watts only.
Fire hazard.
