5.7
To prevent any risk of injury
or damage to the vehicle,
only crank the jack until the
wheel you are replacing is
a maximum of 3 centimetres off the
ground.
– start cranking the jack using handle 4
to position the jack head in the centre
of plate mounting 2 (which should be
pushed slightly under the vehicle).
– turn handle 4 several times to lift the
wheel off the ground.
CHANGING A WHEEL (1/2)
Vehicles equipped with jack and
wheel wrench
If necessary, remove the wheel trim.
– Undo the wheel bolts as shown
by the arrow using wheelbrace 1.
Position wheelbrace 1 so that you
press down on it.
– Position jack 3 horizontally. The
jack head must be positioned at the
same height as plate mounting 2, as
close as possible to the wheel con-
cerned.
Switch on the hazard warn-
ing lights.
Keep the vehicle away from
traffic and on a level sur-
face where it will not slip (if neces-
sary, place a solid support under the
jack base).
Apply the parking brake and engage
a gear (first or reverse, or P for auto-
matic transmissions).
Ask all the passengers to leave the
vehicle and keep them away from
traffic.
2
1
3
4
If the vehicle is parked on
the hard shoulder, you must
warn other road users of
your vehicle’s presence
with a warning triangle or with other
devices as per the legislation apply-
ing to the country you are in.
If the vehicle is not equipped with
the jack and wheel wrench, these
can be obtained from an approved
dealer.
