Renault Latitude - INTERIOR LIGHTS: Changing Bulbs; Courtesy Light

5.22
Courtesy light
Unclip lens 1 using a flat-blade screw-
driver type tool under the courtesy light.
Remove the bulb concerned;
Bulb type: W5W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
INTERIOR LIGHTS: changing bulbs (1/3)
Front door lights
Unclip light 2 using a flat-blade screw-
driver type tool under each side of the
front door light.
When using a tool, place a cloth on the
mirror to prevent scratching.
Bulb type: W5W.
2
1
Courtesy mirror light 3
Unclip the light cover using a flat-blade
screwdriver type tool under the cover.
Place a cloth on the mirror to prevent
scratching.
Replace the bulb.
Bulb type: W5W.
3
