Renault Master - Page 80

1.66
ENG_UD56993_1
sieges enfant : fixation par système isofix (X62 - Renault)
Jaune Noir Noir texte
CHILD SEATS: attachment using the ISOFIX system (1/12)
The table below summarises the information already shown in the diagram on the following pages, to ensure the appli-
cable regulations are respected.
5-seater Combi version
Front seats
Rear seats
Child seat group
Weight of
the child
Size of
Isofix seat
2nd row side seats
2nd row
centre seat
Behind driver
Behind front
passenger
Carrycot fitted across
the vehicle
Group 0
< 10 kg F, G X X X X
Rear-facing shell seat
Group 0 or 0 +
< 13 kg E X IL (1) X X
Rear-facing seat
Group 0+ and 1
< 13 kg and
9 to 18 kg
C, D X IL (1) X X
Forward-facing seat
Group 1
9 to 18 kg A, B, B1 X IUF - IL (2) X IUF - IL (2)
Booster seat
Group 2 and 3
15 kg to
25 kg and
22 to 36 kg
X X X X
