Kit de gonflage des pneumatiques (BFB - KFB - Renault)
TYRE PRESSURE KIT (2/3)
In the event of a puncture, use the kit
located in the luggage compartment
or underneath the luggage compart-
ment floor (depending on the vehicle).
➥ 3.54.
Vehicle fitted with a tyre pressure
monitoring system
In the event of under-inflation (punc-
tures, under-inflation etc.), the
warning light appears on the instrument
panel. ➥ 2.32.
Before using the kit, park
the vehicle at a sufficient
distance from traffic, switch
on the hazard warning
lights, apply the parking brake, ask
all passengers to leave the vehicle
and keep them away from traffic.
Note: While the container empties
(approx. 30 secs), the pressure
gauge 6 briefly shows pressure up to
6 bar, then the pressure drops.
– Adjust the pressure: to increase
it, continue inflation with the kit; to
reduce it, press button 8.
If the vehicle is parked on the hard shoulder, you must warn other road
users of your vehicle’s presence with a warning triangle or with other de-
vices as per the legislation applying to the country you are in.
Engine running, handbrake applied:
– Connect the compressor hose 4 to
the container inlet 9;
– remove the cap from the container
inflation adapter 3;
– unscrew the valve cap on the rele-
vant wheel and screw on the contai-
ner’s inflation adapter 3;
– disconnect any accessories pre-
viously connected to the vehicle’s
accessories sockets;
– the end piece 7 must be plugged in
to the vehicle accessories socket;
– press the 5 switch to inflate the
tyre to the recommended pressure
➥ 4.13 ;
– after a maximum of 15 minutes, stop
inflating and read the pressure (on
pressure gauge 6).
5 63
9
7
4
8
