1.75
ENG_UD60344_1
Tableau de bord : afficheurs et indicateurs (BFB - KFB - Renault)
DISPLAYS AND INDICATORS (4/9)
Instrument panel B
It lights up when the ignition is switched
on. In some cases, the appearance of a
warning light is accompanied by a mes-
sage.
Depending on the vehicle, you can cus-
tomise your instrument panel with the
content and colours of your choice.
For vehicles fitted with a multimedia
screen, refer to the equipment instruc-
tions.
For vehicles not fitted with a multimedia
screen ➥ 1.92.
B
Coolant temperature indicator 16
In normal use, indicator 16 should be
before area 17. Under “intensive” op-
erating conditions, the needle may ap-
proach this zone. This is not serious
unless the warning light
® comes
on accompanied by a message on the
instrument panel and a beep.
Speedometer 18
Depending on the style selected, the
display varies.
16
17
Overspeed buzzer
Depending on the vehicle and country,
the
 warning light is displayed
and a beep sounds. This sounds as
soon as the vehicle exceeds 74 mph
(120 km/h). The warning light remains
on as long as the vehicle speed is over
74 mph (120 km/h).
Rev counter 19
(graduations x 1000)
This is displayed differently according
to how the instrument panel is custom-
ised. Depending on the style selected,
it may not be displayed.
Driving style indicator 20 ➥ 2.22.
20
18
19
