1.56
ENG_UD60338_1
sieges enfant : fixation par système isofix (BFB - KFB - Renault)
The table below summarises the information already shown on the diagram on the previous pages, to ensure the regula-
tions in force are respected.
CHILD SEATS: attachment using the isofix system (2/3)
Type of child seat
Weight of
the child
Seat size ISOFIX
Front passenger
seat
Rear side seats Rear centre seat
Carrycot fitted across
the vehicle
Group 0
< 10 kg F, G X X X
Rear-facing shell
seat
Groups 0 or 0 +
< 10 kg and
< 13 kg
E X IL (1) X
Shell seat/rear-facing
seat
Groups 0+ and 1
< 13 kg and 9 to
18 kg
C, D X IL (1) X
Forward-facing seat
Group 1
9 to 18 kg A, B, B1 X IUF - IL (2) X
Booster seat
Groups 2 and 3
15 to 25 kg and
22 to 36 kg
X IUF - IL (2) X
Seat i-Size X i-U X
(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a child seat in the front passenger seat, make sure that the
front passenger airbag has been deactivated. ➥ 1.58.
