AIR VENTS (air outlets)
1 - left-hand front window demister
2 - left-hand side air vent
3 - windscreen demisting vents
4 -centreairvents
5 - control panel
6 - right-hand side air vent
7 - right-hand side window demister
vent
8 -footwell heater outlet
