3.24
SUN SHADES
Windscreen blind
If vehicle is equipped, remove the
pocket containing the storage
compartment blind located
underneath the front right-hand
seat. Unroll the blind then insert
side frames 2.
Position feet 3 (as far apart and as
near to the windscreen as possible)
on the dashboard. Then press the
frames to insert upper mountings 1
into the trim pieces on each side of
the windscreen.
To retract the blind, proceed in the
reverse order of removal.
It is forbidden to drive
the vehicle with the
windscreen sun blind in
position.
Side sun blinds
Pull tab 5 forwards and tab 6
towards the rear of the vehicle until
they both click into their respective
housings 4 and 7.
