3.41
REAR PARCEL SHELF
Rear parcel shelf
To remove:
- unhook both return straps 1,
- unhook sun blind 2 (depending on
vehicle),
- detach flexible section A attached
to the bench seat seatback
(depending on vehicle),
- lift the parcel shelf then unclip it
upwards.
To refit, proceed in the reverse order
to removal.
Do not place any objects,
especially heavy or hard
objects, on the parcel shelf.
Thesemayposeariskto
the vehicle occupants if the driver
has to brake suddenly or if the
vehicle is involved in an accident.
Locations for anchorage points 3
These are for securing items
transported in the luggage
compartment (see the information
on transporting objects in the
luggage compartment).
Depending on the vehicle, a net for
retaining luggage on the floor,
located in the storage compartment
under the passenger seat, may be
attached to these hooks.
