1.21
FRONT SEATS WITH ELECTRIC ADJUSTMENT
Switches 1, 3 and 4 recall the stored
seat positions: switch 1 is for seat
base position and switches 3 and 4
are for seatback adjustment.
If fitted in the vehicle, button 2 is
used for storing the chosen driving
position. It is possible to store a
driving position using the
RENAULT Card.
The system operates:
- with the RENAULT Card in the
Accessories position (first notch);
- on vehicles fitted with button 2;
this can also be used to open the
driver’s door, with the ignition
switched off, for approximately
40 minutes.
For safety reasons, make
these adjustments only
when the vehicle is
stationary.
Seat adjustments: switch 1
To move forwards
Move it forwards.
To move backwards
Move it backwards.
To raise
Lift the rear of the switch.
To lower
Lower the rear of the switch.
To tilt
Lift or lower the front of the switch.
To ensure that the
effectiveness of the seat
belts is not reduced, we
would advise you not to
recline the seatbacks too far.
Make sure the seatback is locked
in place correctly.
No objects should be placed on
the floor (area in front of driver)
as these objects could slide
under the pedal during braking
manoeuvres, thus obstructing its
use.
