1.22
FRONT SEATS WITH ELECTRIC ADJUSTMENT (continued)
Seatback adjustment
To tilt the upper seatback:
Move switch 3 forwards or
backwards.
To tilt the entire seatback:
Move switch 4 forwards or
backwards.
Heated seats
With the ignition on, move switch 5.
A warning light on the instrument
panel comes on.
The system, which is equipped with
a thermostat, determines whether
heating is necessary.
For safety reasons, make
these adjustments only
when the vehicle is
stationary.
To ensure that the
effectiveness of the seat
belts is not reduced, we
would advise you not to
recline the seatbacks too far.
Make sure the seatback is locked in
place correctly.
No objects should be placed on the
floor (area in front of driver) as
these objects could slide under the
pedal during braking manoeuvres,
thus obstructing its use.
