RH850/F1x StarterKit V3 User Manual
R01UH0724ED0120 Page 4
January 2018
1. Introduction
The ‘RH850/F1x StarterKit’ serves as a simple and easy to use platform for evaluating the
features and performance of Renesas Electronics’ 32-bit RH850/F1x microcontrollers.
Features:
• Connections for on-chip debugging and flash memory programming
• Access to all microcontroller I/O pins
• User interaction through potentiometer, rotary switch, buttons and LEDs
• Serial interface connections for
− 1x RS232
− 1x LIN
− 2x CAN-FD (RH850/F1L version does only support High Speed CAN)
− 1x FlexRay (RH850/F1H, F1KM-S4 and F1KH-D8 version only)
− 1x Ethernet 100Base-T (RH850/F1H, F1KM-S4 and F1KH-D8 version only)
• Power supply by RENESAS E1 On-Chip debugger or externally (12V DC input)
• Support of different RH850/F1x family members
− RH850/F1L
− RH850/F1K
− RH850/F1H
− RH850/F1KM-S4
− RH850/F1KH-D8
This document will describe the functionality provided by the StarterKit and guide the user
through its operation. For details regarding the operation of the microcontroller refer to the
RH850/F1x User Manuals.
