Renesas RH850 F1 Series User Manual

RH850/F1x StarterKit V3 User Manual
R01UH0724ED0120 Page 8
January 2018
Jumper Description Setting Note
J5
MCU power distribution
(Note: setting 7-8 for further
expansion)
1 – 2
REG0VCC supply
3 – 4
EVCC/AVREF supply
5 – 6
BVCC supply
7 – 8 REG1VCC
J6
CAN0/1 transceiver NSIL
enable to MCU connector
1 – 2
CAN0NSIL ↔ P1_1
3 – 4
CAN0NSIL ↔ P2_6
J7
CAN0/1 transceiver TX/RX to
MCU connector
1 – 2
CAN0TX ↔ P1_3
3 – 4
CAN0RX ↔ P1_2
5 – 6
CAN1TX ↔ P1_13
7 – 8
CAN1RX ↔ P1_12
J8
FLEXRAY transceiver TX/RX
to MCU connector
(RH850/F1H and
RH850/F1KM-S4 only)
1 – 2
FR_RXD ↔ P10_14
3 – 4
FR_TXEZ ↔ P10_11
5 – 6
FR_TXD ↔ P11_1
J9
Digital LPS input to MCU
connector
1 – 2
DIN ↔ P8_1
3 – 4
SELDP0 ↔P0_4
5 – 6
SELDP1 ↔ P0_5
7 – 8
SELDP2 ↔ P0_6
9 – 10
DPO ↔ P0_0
J11 VBAT selector 1 – 2
VBAT ↔ external 12V
2 – 3
VBAT ↔ 5V
J12
Blue LED Circle to MCU
connector
1 – 2
SPI driver LE↔P1_14
3 – 4
SPI driver OE#↔P1_15
5 – 6
SPI driver CLK↔ P0_14
7 – 8
SPI driver SI↔ P0_13
9 – 10
SPI driver SO↔ P0_12
J13 RGB LED Connector
1 – 2
R_PWM feedback ↔ AP0_1
3 – 4
G_PWM feedback ↔ AP0_3
5 – 6
B_PWM feedback ↔ AP0_2
J14
Potentiometer to MCU
Connector
1 – 2
POT1 ↔ AP0_0
3 – 4
APO↔P0_1
