Table 22: RH850/F1KM-S4 Power supply architecture with mixed supply 5V & 3.3V
Case 14 – Mixed Supply 5V & 3.3V
Condition
REGVCC = 3.3V
EVCC = 3.3V
BVCC = 3.3V
A0VREF = 3.3V
A1VREF = 5V
Port Function
AP0 – Port usable with analog or digital function
P8 – Port usable with analog or digital function
P9 – Port usable with analog or digital function
AP1 – Port usable with analog or digital function
P18 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V, reduced AD conversion range between 0V
to 3.3V
P19 – Port usable with analog or digital function, analog input
voltage limited to max. 3.3V, reduced AD conversion range between 0V
to 3.3V
Limitation
Analog port function limitation applies to P18 and P19

Operation permitted
Table 23: RH850/F1KM-S4 Power supply architecture with single supply 3.3V
Case 15 – Single Supply 3.3V
Condition
REGVCC = 3.3V
EVCC = 3.3V
BVCC = 3.3V
A0VREF = 3.3V
A1VREF = 3.3V
Port Function
AP0 – Port usable with analog or digital function
P8 – Port usable with analog or digital function
P9 – Port usable with analog or digital function
AP1 – Port usable with analog or digital function
P18 – Port usable with analog or digital function
Limitation
No limitation applies

Operation permitted
3FFh
0V
3.3V
5V
2A3h
0V
3.3V
5V
Note: Con ver sion r ange ex ampl e base d on 10-bit ADC resolution
Analog input channel on AP1
Analog input channel on P18 and P19
 Red uced AD c onversion range
Available
voltage range
Available
voltage range
